| APPLICATIONS | Suitable for Purification of Brackish / Tap Water |
| PURIFICATION CAPACITY | Upto 20 LPH* |
| BODY MATERIAL | ABS Food Grade Plastic |
| MOUNTING | On the Wall / Counter-Top |
| DIMENSIONS(MM) | L 405 W 330 H 470 |
| INLET WATER PRESSURE/TEMP (MIN) | 0.3 kg / cm2 or 4.267psi / 10°C |
| INLET WATER PRESSURE/TEMP (MAX) | 3 kg / cm2 or 42.67psi / 35°C |
| FILTER CARTRIDGES | Sediment, Carbon Block Filter, UF & Post Carbon |
| AUTO-FLUSHING SYSTEM | Yes |
| UV LAMP WATTAGE | 11 Watt |
| WEIGHT | 10.800 kg |
| STORAGE CAPACITY | 15 L |
| PURIFICATION PRODUCTION RATE | 15 L/hr. |
| MAXIMUM DUTY CYCLE | 75 L/day |
| POWER CONSUMPTION | 60 W |
| MEMBRANE TYPE | Thin Film Composite RO |
| BOOSTER PUMP VOLTAGE | 24 V DC |
| MAINS VOLTAGE | 100 - 300 V~ AC / 50 Hz, 800mA |
| Installation, Warranty & After-Sales Service • Installation charges will be paid by customer. • Product warranty shall be effective from the date of installation. Warranty coverage period for different parts shall be as under: • All Electricals and Mechanical parts - 1 Year Consumables like RO Membrane & UF Membrane - 1 Year Consumables like Sediment Filter, Carbon Filter & Post Carbon Filter - 6 Months • After-Sales service shall be provided at customer's premises on demand basis **Purification capacity tested on raw water with TDS level of 750 ppm at room temperature |
|
